FDR180-1200-8t
Perameters:
Max Thrust：8000kg (8 Ton)
Stroke：1200mm
Speed：330mm/s
Motor Power：31.4KW
Lead Screw：20mm
Reduction Ratio ：2 ：1
Product Advantages:
1. Ultra-high thrust output up to 8000kg, suitable for heavy-duty industrial working conditions.
2. Equipped with 31.4KW high-power servo motor, strong power and stable driving performance.
3. Standard 1200mm long stroke and 330mm/s fast running speed, meeting diverse production requirements.
4. High-strength alloy ball screw structure, durable and long service life.
5. Closed-loop servo control system, high positioning accuracy and excellent repeat motion performance.
6. Fully electric drive design, no oil leakage, cleaner and more environmentally friendly than hydraulic cylinders.
7. Low noise operation, simple maintenance and greatly reduced later operating costs.
8. Customizable stroke, speed, installation method and control program for different industrial equipment.
Application Industries:
1. Heavy industrial pressing and stamping equipment
2. Hydraulic cylinder replacement and energy-saving renovation projects
3. Metallurgical machinery and metal forming production lines
4. Construction machinery and large engineering equipment supporting
5. Auto industry fixture clamping and assembly automation
6. Large intelligent logistics lifting and pushing equipment
7. Industrial testing machines, fatigue testing and force detection equipment
8. Custom heavy-duty linear motion automation system.
